FEATURES
- Low insertion loss
- Low back reflection loss
- Customized design is available
- Easy for installation
- Environmentally-friendly
SPECIFICATIONS
| Mode Type |
Singlemode |
Multimode |
Singlemode |
| Connector Type |
LC, FC, SC, ST |
LC, MU, FC, SC, APC |
|
| Insertion Loss (dB) |
≦0.3 |
≦0.4 |
≦0.3 |
| Return Loss (dB) |
>50 |
- |
61~68 |
| Operating Temp. (°C) |
-20 ~ +70 |
||
| Storage Temp. (°C) |
-55 ~ +85 |
||
Applicable Fiber Cable Specifications & Fiber Transmission Performance
| Mode Type |
Singlemode (1310/1550nm) |
Multimode (850/1300nm) |
|
| Mode Field Diameter (μm) |
9/125 |
50/125 |
62.5/125 |
| Maximum Attenuation (dB/km) |
1.0/0.75 |
3.5/1.5 |
3.75/1.5 |
| Typical Attenuation @23°C (dB/km) |
0.5/0.4 |
3.0/1.0 |
3.0/1.0 |
| Minimum Bandwidth (MHz/km) |
- |
400/400 |
160/500 |
